サインインして注文 →The NanoPi T6 microcomputer is the flagship platform for professionals and enthusiasts. The model is designed for high-performance computing at the edge. It is ideal for AI inference, home servers and multimedia. This device will take your projects to the next level.
The NanoPi T6 microcomputer is built on a Rockchip RK3588 processor. This is an eight-core architecture with two clusters. Four Cortex-A76 cores accelerate to 2.4 GHz. Four more Cortex-A55 cores operate at 1.8 GHz. Built-in Mali-G610 MP4 GPU supports OpenGL and Vulkan.
Video processor decodes 8K60 video in H.265 and VP9 formats. Neural processor delivers 6 TOPS for AI tasks. LPDDR4X RAM capacity reaches 16 GB. Built-in eMMC storage capacity up to 256 GB. The board supports booting from microSD cards. PCB size is 110×80mm.
A special feature of the model is the presence of two 2.5G Ethernet ports. It is an ideal solution for a powerful network gateway. The board has three HDMI ports: two outputs and one input. One output supports 8K@60Hz resolution. HDMI input allows you to record video streams up to 4K60. The M.2 M-Key slot supports high-speed NVMe SSDs.
M.2 E-Key slot is designed for Wi-Fi and Bluetooth modules. The board is equipped with USB 3.0 and USB Type-C ports. USB-C supports 4K60 image output and power. 40-pin GPIO gives access to UART, SPI and I2C. All these interfaces make the board universal for any task.
Manufacturer FriendlyELEC is a well-known developer of single board computers. The company specializes in ARM boards for developers and manufacturers. The brand's products are distinguished by high quality and reliability. FriendlyELEC offers open source software and documentation. All boards undergo strict production control. The manufacturer is actively updating the firmware and Linux kernel. FriendlyELEC provides long-term support for its products. Brand models are popular among developers around the world.
A special feature of FriendlyELEC boards is their specialization for edge computing. NanoPi T6 model supports multiple operating systems. These are Ubuntu, Debian, Android and Android TV. The board works with OpenMediaVault to create a NAS. FriendlyWrt turns it into a powerful router. NanoPi T6 is ideal for rapid prototyping.
The board can be easily integrated into final products. Ideal for machine vision systems. NanoPi T6 is used in industrial controllers and robots. The board is used in video surveillance systems and on advertising screens. Optional CNC housing protects the board and adds style. It is an ideal choice for developers and manufacturers.
