DJI Zenmuse S1 Floodlight

Order the professional DJI Zenmuse S1 spotlight for your Matrice drone!

Transform your industrial drone into a powerful tool for night operations. The DJI Zenmuse S1 is the first official DJI lighting product. It is specially designed for multi-purpose platforms such as Matrice 350 RTK and Matrice 300 RTK. Featuring advanced LEP (Laser Excited Phosphor) laser technology, it delivers an incredibly bright and focused beam.

You will be able to see details where others are powerless. This device will become an indispensable assistant for rescue services, security services and inspections working in the dark.

• Record illumination range up to 500 meters. Effectively illuminates objects at extreme distances, providing maximum situational awareness.

• Four lighting modes for any task. Low beam (15°), high beam (4°), combined mode and strobe (5 Hz) for signaling.

• Intelligent camera synchronization. Automatically adjusts the beam angle to the camera's field of view, ideal for spot illumination of objects.

• Reliability in any conditions. IP54 dust and moisture protection and a wide operating temperature range from -20 to +40°C.

• Thoughtful safety and energy efficiency. The body does not heat above 50°C, and in high beam mode it consumes only 17 W, saving the drone’s battery power.

How does this powerful beam of light work and where is it used?

LEP (Laser Excited Phosphor) technology in Zenmuse S1 creates a highly concentrated light output. It does not dissipate over long distances. This is ideal for spot illumination of objects. Control is via the DJI Pilot 2 app, where the operator can select modes, adjust brightness and activate the strobe.

Four modes - “low beam” (15°, up to 150 m) is suitable for general illumination of a landing or search site. High beam (4°, up to 300 m) for identifying distant targets, combined mode (up to 500 m) for maximum visibility, and strobe for attracting attention.

Buy the DJI Zenmuse S1 Floodlight from the COPTERPARTS store. This is a professional solution that will transform your industrial drone into a powerful tool for night operations, ensuring safety and efficiency in the most challenging environments. Our specialists will help you choose and answer your questions. Place your order right now on our website.

Specifications

• Dimensions: 125×152×171 mm (L×W×H)
• Weight: 760±10g
• Waterproof: IP54
• Operating temperature range: -20° to 40° C (-4° to 104° F)
• Storage temperature range: -20° to 60° C (-4° to 140° F)
• Rated power: 120 W (Matrice 400) / 68 W (Matrice 300 RTK/Matrice 350 RTK)
• Compatibility: Matrice 300 RTK (requires DJI RC Plus), Matrice 350 RTK, Matrice 400

Lighting options

• Auxiliary Light: The remote control buttons can be customized to turn the light on/off, adjust the brightness, or change the lighting mode.
• Max. central illumination:

35 lux at 100 m (Matrice 300 RTK/Matrice 350 RTK, both modes enabled)

• 40 lux at 100 m (Matrice 400, both modes on)
• Dimming Mode: Analog Dimming
• Lighting Modes: Low Beam Mode, High Beam Mode, Both Modes On
• Strobe Mode: 5Hz Strobe
• Gimbal Sync: Supports synchronized control with other useful
• loads equipped with a gimbal.

Typical color temperature:

• Typical value 6500K (low beam mode)
• Typical value 7500K (high beam mode)
• Lighting control: Light on/off, brightness adjustment
• Central low beam: 13 lux at 100 m (Matrice 300 RTK/Matrice 350 RTK, low beam mode)
• 20 lux at 100 m (Matrice 400, low beam mode)
• Central high beam: 30 lux at 100m (high beam mode)
• Effective lighting distance: 500m (Both modes included)
• Effective lighting angle:
• 15±1° (10% relative illumination, low beam mode and "Both on" mode)
• 4±0.5° (10% relative illumination, high beam mode)

Special Features

• Eye Protection: Automatically limits brightness to 40% when not in flight
• Payload protection: LED protection, LEP overheat protection, overcurrent protection and
• Power protection to prevent damage.
• Intelligent Beam Alignment: When used with Zenmuse H30 series on Matrice 400 Zenmuse
• S1 uses gimbal synchronization to automatically align the spotlight beam with the field
• camera view.
• Synchronized Control: By installing two Zenmuse S1 on the Matrice 400, you can simultaneously
• control both spotlights.

Suspension

• Angular vibration range: Hover: ±0.01°; Flight: ±0.02°
• Controllable range: Tilt: -120° to +60°; Panning: ±320°
• Mechanical Range: Roll: ±55.8°; Tilt: -129° to +73°; Pan: ±327°
• Stabilization: 3-axis (tilt, roll, pan).
