Servo drive Corona DS-929MG

Order the Corona DS-929MG servo drive for precise control of your drone or aircraft!

The Corona DS-929MG servo drive is a compact digital servo drive with a metal gearbox. The model provides high speed and excellent torque for small models. It is ideal for airplanes, helicopters and robotics projects. With this servo drive, your equipment will receive reliable and precise control.

• Metal gearbox for long and reliable service.
• High torque of 2.2 kg cm at 6.0 V.
• Fast response with a speed of 0.10 seconds per 60 degrees.
• Compact weight of 12.5 grams for minimal load on the model.
• Ball bearing for smooth and precise running.

Buy a reliable digital servo for small models

Corona DS-929MG servo drive operates in the voltage range 4.8–6.0 V. At 4.8V it reaches a speed of 0.12s/60°. At 6.0 V the speed increases to 0.10 s/60°. Torque is 2.0 kg cm at 4.8 V. At 6.0 V it reaches 2.2 kg cm. Dead zone does not exceed 3 microseconds. This guarantees an immediate response to the signal.

Case dimensions are 22.5×11.5×24.6 mm. Servo weight is 12.5 grams. Operating current is 200 mA at 4.8 V and 240 mA at 6.0 V. The model is equipped with MR85 ball bearing. The length of the connecting wire reaches 215 mm. Operating temperature range is -20 to +60 °C.

A special feature of the model is the use of a metal gearbox. It provides high strength and durability. Digital control with MOSFET drive provides high precision. The servo drive is ideal for controlling aircraft surfaces. It also works great in helicopters and crawlers. Model suitable for camera gimbals and robotics. Ball bearing reduces friction and wear. The servo drive ensures smooth and silent movement.

Choose high-quality components from the manufacturer Corona

The manufacturer of Corona is Wuxi CORONA Electronic & Technology Co., Ltd. It was founded in 2006 and is a leading RC parts manufacturer in China. Corona is known for lightweight and reliable receivers and servos. The brand's products are certified to CE, ROHS and ISO9001 standards. Corona specializes in the development of servos and 2.4 GHz combos for Futaba and JR systems. The company is export-oriented and supplies products all over the world.

The peculiarity of Corona servos is their excellent price-quality ratio. The DS-929MG is an extremely popular choice among modellers. It has gained trust due to its reliability and availability. Servo offers high performance at a budget price. This makes it an ideal choice for beginners and experienced pilots. Corona is constantly improving its technologies and materials. You get a reliable device for your projects.

• Dimensions: 22.5 x 11.5 x 24.6 mm
• Operating speed: 0.07 sec.60° / 0.06 sec.60°
• Operating speed: 40o/one-way pulse, travel 400 µs
• Operating voltage: 4.8V/6.0V
• Braking torque (4.8V): 1.5 kg cm / 1.7 kg cm
• Operating temperature range: from -20 to +60 degrees Celsius.
• Dead zone: no more than 3 µs
• Potentiometer: 2 sliders/Direct drive
• Ball bearing: MR85
• Connecting wire length: 215mm
