Sensor Garmin Panoptix LiveScore Plus LVS34+GLS
The latest LiveScope technology, LiveScope Plus provides improved resolution, reduced noise, sharper images and better target separation.
USD · Volume pricing available
Catégories:
Certifications
Global Shipping 7-14 Days
DHL, FedEx, UPS, Air & Sea
Genuine Products
Authorized distribution
Export License Ready
ECCN, CO, CI, PL, EUS docs
24/7 Tech Support
Pre & post sales
Export Compliance
EAR99AI confidence 85% · NLR — No license required. Standard end-use statement recommended.
Buyer Tier Benefits
Tier discounts stack with volume pricing. Automatically applied after your first order.
Order the Garmin Panoptix LiveScore Plus echo sounder sensor at a competitive price!
Technical Parameters
- Dimensions
Black GLS 10 sonar box: 9.7″ x 5.9″ x 2.6″ (24.5 x 14.9 x 6.5 cm);
LVS34 transducer: 6.4″ x 3.1″ x 1.9″ (16.2 x 7.8 x 4.8 cm). - Weight
GLS 10 sonar black box: 4.3 lb (2.0 kg)
LVS34 transducer: 2.25 lb (1.02 kg)
Waterproof IPX7
Transducer Beam Width 20° x 135°
Transducer cable length 20 feet
Number of converter contacts 21 - Temperature range
GLS 10 Black Box: Operating temperatures: -15 C to 70 C
Panoptix LiveScope LVS34 Sensor: Operating Temperatures: 0 C - 40 C - Electrical characteristics
Input voltage 10-32 V
Typical power consumption 21 W, maximum 58 W
Fuse 7.5 A
Compass distance 4″ (0.1 m) - Sonar Features
Frequency 530 - 1,100 kHz
Transmission power 500 W
Maximum depth down and forward: 200′ (61.0 m)
Live sonar type
Target separation @100′ 14″
Perspective Mode: Mount included - Connectors
Garmin Marine Network Ports: 1 (small connector).
In conclusion, the Garmin Panoptix LiveScope Plus LVS34+GLS is an advanced sensor that provides fishermen and underwater explorers with the most accurate information about what is underwater. Its use in fishing boats and scientific research makes it one of the most sought after devices on the market.
