The Chief racing engine was developed by Lumenier in collaboration con Profesional racing Dron pilot Alex “Chief” Campbell. This is a high-performance, ultra-lightweight racing engine designed para maximum performance on the FPV race track.
EUR · Precio unitario orientativo de referencia. Los precios por volumen y de proyecto se facilitan en el presupuesto; el MOQ y los plazos varían según el producto.
Disponibilidad y plazos
Envío desde Hong Kong · DAP o FOB Hong Kong.
Envío rastreado a todo el mundo
DHL · FedEx · UPS · EMS, además de flete aéreo, marítimo y ferroviario
Licencia de exportación lista
Documentos ECCN, CO, CI, PL, EUS
Product prices and shipping quotes do not include import duties, taxes or customs clearance fees — these are charged by the destination customs authority. Estimate them above, or read the import duties & VAT guide.
Productos genuinos
Distribución autorizada
Soporte de ingeniería
Selección preventa y RMA posventa
Secure, milestone-based payment
T/T 30/70 terms and irrevocable L/C over US$50,000. Funds follow agreed milestones — you never pay an unknown seller upfront.
Payment protectionVetted supplier, Aegisky as contracting window
Suppliers pass KYC/KYB and export-capability review; Aegisky — not an anonymous third party — is your single contracting and communication window.
View supplier profileExport compliance on every controlled order
ECCN classification, sanctions screening and end-use/end-user documentation are handled before quotation is finalised.
Export compliance14-day defective/DOA protection & warranty handling
Defective or dead-on-arrival items are accepted within 14 days via RMA; warranty claims and spare-parts support are handled through the trade desk.
Returns & warrantyLos precios de los componentes son públicos. Inicie sesión para ver precios para flotas, guardar cotizaciones, rastrear pedidos y comprar más rápido; crear una cuenta comercial toma un minuto.
Iniciar sesión para pedir →HF: 2050
Configuration: 12N14P
Windings: 9-turn DLRK
Ending: D (Delta)
Stator diameter: 22mm
Stator height: 7mm
Stator lamination thickness: 0.15mm
Magnets: Curved N52SH
Bearing size: 9x4x4
Shaft: titanium alloy 5mm
Inner shaft diameter: titanium alloy 4mm
Base mounting pattern: M3 thread 16×16 mm
Motor size: 27×19mm
Weight: 28g (short wires)
Cells: (LiPo) 4-6 S
Motor wire length: 150mm/20AWG
