Communication frequency: 5.730 - 5.815 GHz;
EUR · Unverbindlicher Stückpreis zur Orientierung. Mengen- und Projektpreise erhalten Sie im Angebot; MOQ und Lieferzeiten variieren je nach Produkt.
Verfügbarkeit & Lieferzeiten
Versand aus Hongkong · DAP oder FOB Hongkong.
Sendungsverfolgung weltweit
DHL · FedEx · UPS · EMS sowie Luft-, See- und Schienenfracht
Exportlizenz verfügbar
ECCN-, CO-, CI-, PL-, EUS-Dokumente
Product prices and shipping quotes do not include import duties, taxes or customs clearance fees — these are charged by the destination customs authority. Estimate them above, or read the import duties & VAT guide.
Originalprodukte
Autorisierter Vertrieb
Technischer Support durch Ingenieure
Auswahl vor dem Kauf und RMA danach
Secure, milestone-based payment
T/T 30/70 terms and irrevocable L/C over US$50,000. Funds follow agreed milestones — you never pay an unknown seller upfront.
Payment protectionVetted supplier, Aegisky as contracting window
Suppliers pass KYC/KYB and export-capability review; Aegisky — not an anonymous third party — is your single contracting and communication window.
View supplier profileExport compliance on every controlled order
ECCN classification, sanctions screening and end-use/end-user documentation are handled before quotation is finalised.
Export compliance14-day defective/DOA protection & warranty handling
Defective or dead-on-arrival items are accepted within 14 days via RMA; warranty claims and spare-parts support are handled through the trade desk.
Returns & warrantyKomponentenpreise sind öffentlich. Melden Sie sich an, um Flottenpreise zu sehen, Angebote zu speichern, Bestellungen zu verfolgen und schneller zu bestellen – ein Geschäftskonto ist in etwa einer Minute erstellt.
Anmelden & bestellen →The CADDX Walksnail Ascent VRX transmitter is a compact and lightweight module designed to receive a signal from the Walksnail Ascent digital HD system. The device is equipped with an HDMI output, which allows you to connect it to any FPV goggles, monitors and even TVs. Ascent VRX provides significantly cleaner and more stable images than analog systems, making it an excellent choice for new pilots and hobbyists who want to make the transition to digital video without breaking the bank.
The receiver picks up a digital radio signal from the video transmitter (VTX) of the Ascent system in the range of 5.725–5.829 GHz. It decodes the signal and outputs the image via the HDMI port in resolutions up to 1080p at 60 frames per second. Two omnidirectional antennas with left-hand circular polarization (LHCP) and a radiation efficiency of more than 97% ensure minimal signal loss and reliable reception at a distance of up to 6 km.
Built-in microSD card slot allows you to record live video without external DVR. Power is supplied via a DC 5.5×2.1 mm coaxial connector with a voltage of 7.4–25.2 V, which allows it to be connected to 2–6S batteries.
The receiver supports a high frame rate mode of 720p at 120 fps to reduce latency, which is especially useful in dynamic flights. Fully customizable OSD menus and Canvas Mode support provide seamless Betaflight and INAV OSD integration.
The Ascent VRX model has dimensions of 114.5 × 64 × 24 mm and a weight of 118 grams. Frequency range - 5.725–5.829 GHz. Transmitter Power (EIRP): FCC/SRRC <30 dBm, CE <14 dBm. Bandwidth: 5/10/20 MHz and auto. The HDMI output supports resolutions of 1080p at 50/60 fps and 720p at 50/60/100/120 fps.
The receiver is equipped with two RP-SMA connectors for antennas with LHCP polarization and 2 dBi gain. Interfaces: HDMI, microSD slot (up to 256 GB), DC 5.5×2.1 mm, SH1.0×6PIN and USB Type-C. Video recording format is MP4 (H.264). Supports up to 8 channels in debug mode.
